Rockwell Automation 1408-EMxx PowerMonitor 1000 Unit User Manual
Page 70
70
Publication 1408-UM001B-EN-P - May 2008
Appendix A Powermonitor 1000 Data Tables
12
30125-26
Voltage Phase 3
Magnitude
Volts
0…9,999,999
•
•
•
Shows the present magnitude of
this phase.
13
30127-28
Current Phase 1
Angle
Degrees
0…359.99
•
•
•
Shows the present phase angle
of this channel.
14
30129-30
Current Phase 1
Magnitude
Amperes
0…9,999,999
•
•
•
Shows the present magnitude of
this phase.
15
30131-32
Current Phase 2
Angle
Degrees
0…359.99
•
•
•
Shows the present phase angle
of this channel.
16
30133-34
Current Phase 2
Magnitude
Amperes
0…9,999,999
•
•
•
Shows the present magnitude of
this phase.
17
30135-36
Current Phase 3
Angle
Degrees
0…359.99
•
•
•
Shows the present phase angle
of this channel.
18
30137-38
Current Phase 3
Magnitude
Amperes
0…9,999,999
•
•
•
Shows the present magnitude of
this phase.
19
30139-40
Degrees out of
range
0…360
•
•
•
•
•
When Status = 5, how many
degrees out of range.
20
30141-42
Reserved
0
•
•
•
•
•
Reserved for future use
Wiring Diagnostics Results
Element
No.
Modbus
Address
Element Name
Units
Range
TR
1
TR
2
EM
1
EM
2
EM
3
Description
Volts, Amps, Frequency Results Parameters
CSP File No.
F21
CIP Instance
14
No. of Elements
16
No. of Words
32
Data Type
Float
Data Access
Read
Volts, Amps, Frequency Results
Element
No.
Modbus
Address
Element Name
Range
TR1
TR2
EM1
EM2
EM3
Description
0
30201-2
L1 Current
0.000…9,999,999
•
•
•
Phase 1 scaled RMS Current
1
30203-4
L2 Current
0.000…9,999,999
•
•
•
Phase 2 scaled RMS Current
2
30205-6
L3 Current
0.000…9,999,999
•
•
•
Phase 3 scaled RMS Current
3
30207-8
Average Current
0.000…9,999,999
•
•
•
Average RMS Current
4
30209-10
L1-N Volts
0.000…9,999,999
•
•
•
Phase 1 scaled RMS Voltage
5
30211-12
L2-N Volts
0.000…9,999,999
•
•
•
Phase 2 scaled RMS Voltage
