Rockwell Automation 1408-EMxx PowerMonitor 1000 Unit User Manual
Page 72
72
Publication 1408-UM001B-EN-P - May 2008
Appendix A Powermonitor 1000 Data Tables
6
30313-14
L3 kWatts
+/- 0.000…9,999,999
•
•
Line 3 kWatts
7
30315-16
Total kWatts
+/- 0.000…9,999,999
•
•
Total kWatts
8
30317-18
L1 kVAR
+/- 0.000…9,999,999
•
•
Line 1 kVAR
9
30319-20
L2 kVAR
+/- 0.000…9,999,999
•
•
Line 2 kVAR
10
30321-22
L3 kVAR
+/- 0.000…9,999,999
•
•
Line 3 kVAR
11
30323-24
Total kVAR
+/- 0.000…9,999,999
•
•
Total kVAR
12
30325-26
L1 kVA
0.000…9,999,999
•
•
Line 1 kVA
13
30327-28
L2 kVA
0.000…9,999,999
•
•
Line 2 kVA
14
30329-30
L3 kVA
0.000…9,999,999
•
•
Line 3 kVA
15
30331-32
Total kVA
0.000…9,999,999
•
•
Total kVA
16
30333-34
Metering Iteration
0…9,999,999
•
•
Increments by 1 for each new
metering calculation.
Power Results
Element
No.
Modbus
Address
Element Name
Range
TR1
TR2
EM1
EM2
EM3
Description
IMPORTANT
Only total power values are returned in delta wiring modes.
Zeroes are returned for individual phase values.
Energy Results Parameters
CSP File No.
F23
CIP Instance
16
No. of Elements
19
No. of Words
38
Data Type
Float
Data Access
Read
Energy Results
Element
No.
Modbus
Address
Element Name
Range
TR1
TR2
EM1
EM2
EM3
Description
0
30401-2
Status 1 Count xM
0…9,999,999
•
•
•
Status 1 Count times 1,000,000
1
30403-4
Status 1 Count x1
0…999,999
•
•
•
Status 1 count times 1
2
30405-6
Status 2 Count xM
0…9,999,999
•
•
•
Status 2 Count times 1,000,000
3
30407-8
Status 2 Count x1
0…999,999
•
•
•
Status 2 count times 1
