Rockwell Automation 1408-EMxx PowerMonitor 1000 Unit - Manual (Page 69)

Publication 1408-UM001B-EN-P - May 2008 69
Powermonitor 1000 Data Tables Appendix A
3 30107-8 Current Input
Missing -1…123
• • • • •
Reports on all three phases.
-1 = Test not run.
0 = Test passed.
1 = Phase 1 missing
2 = Phase 2 missing
3 = Phase 3 missing
12 = Phase 1 and 2 missing
13 = Phase 1 and 3 missing
23 = Phase 2 and 3 missing
123 = All phases missing
4 30109-10 Current Input
Inverted -1…123
• • • • •
Reports on all three phases.
-1 = Test not run.
0 = Test passed.
1 = Phase 1 inverted
2 = Phase 2 inverted
3 = Phase 3 inverted
12 = Phase 1 and 2 inverted
13 = Phase 1 and 3 inverted
23 = Phase 2 and 3 inverted
123 = All phases inverted
5 30111-12 Voltage Rotation -1…132
• • • • •
Reports on all three phases. The
reported sequence represents
each phase. Example: 123 =
Phase 1 then phase 2 then phase
3
-1 = Test not run
4 = Invalid rotation
1…132 designating phase and
rotation.
6 30113-14 Current Rotation -1…321
• • • • •
Reports on all three phases. The
reported sequence represents
each phase. Example: 123 =
Phase 1 then phase 2 then phase
3
-1 = Test not run
4 = Invalid rotation
1…321 designating phase and
rotation.
7 30115-16 Voltage Phase 1
Angle Degrees 0…359.99
• • •
Shows the present phase angle
of this channel. Should always be
0 degrees for voltage phase 1.
8 30117-18 Voltage Phase 1
Magnitude Volts 0…9,999,999
• • •
Shows the present magnitude of
this phase.
9 30119-20 Voltage Phase 2
Angle Degrees 0…359.99
• • •
Shows the present phase angle
of this channel.
10 30121-22 Voltage Phase 2
Magnitude Volts 0…9,999,999
• • •
Shows the present magnitude of
this phase.
11 30123-24 Voltage Phase 3
Angle Degrees 0…359.99
• • •
Shows the present phase angle
of this channel.
Wiring Diagnostics Results
Element
No. Modbus
Address Element Name Units Range
TR
1
TR
2
EM
1
EM
2
EM
3
Description
