Publication 1408-UM001B-EN-P - May 2008 79
Powermonitor 1000 Data Tables Appendix A
17 30735-36 kVA Demand 0.000…9,999,999
• •
The average apparent power
during the last demand period.
18 30737-38 Demand PF -100.0…+100.0
• •
The average demand for PF
during the last demand period.
19 30739-40 Reserved 0
• •
Reserved for future use.
20 30741-42 Reserved 0
• •
Reserved for future use.
Energy Log Results
Element
No. Modbus
Address Element Name Range
TR1 TR2 EM1 EM2 EM3
Description
Write Error Status Results Parameters
CSP File No. N27
CIP Instance 20
Applies to All Models
No. of Elements 3
No. of Words 3
Data Type Integer
Data Access Read
Write Error Status Results
Element
No.
Modbus
Address
Element Name Range Description
0 30801 Table Number or
Instance All Write Enabled Tables Indicates the last table that was written.
1 30802 Offending Element Length of current table - 1 If the most recent write was successful this
returns a (-1). If the write was unsuccessful this
is the first rejected element in the table write.
2 30803 Terminal Lock On 0…1 If a write was made to a table that has elements
that are locked this value is 1.
