Appendix
A
Powermonitor 1000 Data Tables
Summary of Data Tables
The Summary of Powermonitor 1000 Data Tables for all
Communication Protocols table summarizes all data tables available
and their general attributes
The rest of the tables detail each specific data table and its associated
elements, such as Modbus address, default value, ranges, and
description.
IMPORTANT
The lock symbol
designates that the parameter that is
marked will not be able to be written when the hardware lock
terminals are connected together.
Summary of Powermonitor 1000 Data Tables for all Communication Protocols
Name of data table
Data
Access
CSP
File No.
CIP
Modbus
Addressing
No of
Elements
TR1
TR2
EM1
EM2
EM3
Refer to
Page
User Configured Table Results
R
F9
1
31601…31632
16
•
45
Analog Input Configuration
RW
F10
3
40001…40014
7
•
•
•
•
•
46
Advanced Configuration
RW
F11
4
40101…40144
22
•
•
•
•
•
47
RS485 Configuration
RW
N12
5
40201…40209
9
•
•
•
•
•
51
Ethernet Configuration
RW
N13
6
40301…40323
23
•
•
•
•
•
52
Time Zone Information
54
Date and Time Configuration
RW
N14
7
40401…40408
8
•
•
•
•
•
57
Log Configuration
RW
N15
8
40501…40512
12
•
•
•
58
Command
W
F16
9
40601…40644
22
•
•
•
•
•
61
Log Request
RW
N17
10
40701…40711
11
•
•
•
•
•
64
Controller Interface
W
N18
11
40801…40808
8
•
•
66
Discrete Result
R
N19
12
30001…30006
6
•
•
•
•
•
67
Wiring Diagnostics Results
R
F20
13
30101…30142
21
•
•
•
•
•
68
Volts, Amps and Frequency
Results
R
F21
14
30201…30232
16
•
•
•
70
Power Results
R
F22
15
30301…30334
17
•
•
•
71
Energy Results
R
F23
16
30401…30438
19
•
•
•
72
