Appendix A Powermonitor 1000 Data Tables
Catalog Number and WIN Parameters
CSP File No. N34
CIP Instance 27
Applies to All models
No. of Elements 19
No. of Words 19
Data Type Integer
Data Access Read
Catalog Number and WIN
Element
No. Modbus
Address Element Name Range Description
0 31501 Catalog # text char pair #1 0…32767 Contains the product number (example: 1408-EM3A-485A, but with
out the dashes). A read of this table returns the catalog # as 4
integers: each integer contains a character pair. For each character
pair, character 1=integer/256 and character 2 = remainder of
integer/256.
1 31502 Catalog # text char pair #2
2 31503 Catalog # text char pair #3
3 31504 Catalog # text char pair #4
4 31505 Catalog # text char pair #4
5 31506 Catalog # text char pair #4
6 31507 Reserved 0 Reserved for future use.
7 31508 Hardware Series 0…25 Indicates the product series letter.
For example, 0=A, 1=B,
8 31509 WIN # text char pair #1 0…32767 Contains the product WIN(Warranty Identification Number). This is
the same alpha-numeric string that can be found on the master
module label (example: 21AW0AT5HO). 5 integers each contains two
characters as displayed by the Catalog parameter method.
9 31510 WIN # text char pair #2
10 31511 WIN# text char pair #3
11 31512 WIN# text char pair #4
12 31513 WIN# text char pair #5
13 31514 Reserved 0 Reserved for future use.
14 31515 Reserved 0 Reserved for future use.
15 31516 Original Model 0 … 10 This number represents the catalog number type.
0 = TR1
1 = TR2
2 = EM1
3 = EM2
4 = EM3
5 through 10 = Reserved
