80 Publication 1408-UM001B-EN-P - May 2008
Appendix A Powermonitor 1000 Data Tables
Unit Run Status Results Parameters
CSP File No. N28
CIP Instance 21
Applies to All models
No. of Elements 25
No. of Words 25
Data Type Integer
Data Access Read
Unit Run Status Results
Element
No. Modbus
Address Element Name Range Description
0 30901 Bulletin Number 1408 Always returns 1408
1 30902 Series Letter 0…8 Indicates the unit hardware series letter, for
example.
0 = A
1 = B
.
.
8 = H
2 30903 Catalog Device Type 0…4 The catalog number type of this device.
0 = TR1
1 = TR2
2 = EM1
3 = EM2
4 = EM3
3 30904 Communication Type 0…1 The communication type of this device
0 = Serial only
1 = both serial and Ethernet
4 30905 Application FRN - The current firmware revision
5 30906 Boot Code FRN - The current boot code revision
6 30907 Default Device ID 1…247 A semi-unique number assigned to a device at the
time it is manufactured. Used for out of the box
communications over DF1 and Ethernet.
7 30908 Accuracy Class 0…3 Indicates the revenue metering accuracy class of
the power monitor as it is shipped from the
factory.
0 = No Class Designation
1 = Class 1
2 = Class 0.5
3 = Class 0.2
