Rockwell Automation 1408-EMxx PowerMonitor 1000 Unit User Manual
Page 53
Publication 1408-UM001B-EN-P - May 2008
53
Powermonitor 1000 Data Tables Appendix A
5
40306
Subnet Mask Byte a
255
0…255
• •
• • •
Specifies the subnet mask to apply to
the IP address.
6
40307
Subnet Mask Byte b
255
0…255
• •
• • •
Specifies the subnet mask to apply to
the IP address.
7
40308
Subnet Mask Byte c
0
0…255
• •
• • •
Specifies the subnet mask to apply to
the IP address.
8
40309
Subnet Mask Byte d
0
0…255
• •
• • •
Specifies the subnet mask to apply to
the IP address.
9
40310
Gateway IP Address
Byte a
128
0…255
• •
• • •
IP address of the gateway to other
subnets for wide area networking.
10
40311
Gateway IP Address
Byte b
1
0…255
• •
• • •
IP address of the gateway to other
subnets for wide area networking.
11
40312
Gateway IP Address
Byte c
1
0…255
• •
• • •
IP address of the gateway to other
subnets for wide area networking.
12
40313
Gateway IP Address
Byte d
1
0…255
• •
• • •
¸ IP address of the gateway to other
subnets for wide area networking.
13
40314
SNTP Mode Select
0
0…2
• •
• • •
This mode selects the mode of the SNTP
function or to disable the SNTP function.
0 = Disable
1 = Unicast - The SNTP address points to
a unicast server.
2 = Anycast Mode - The SNTP address is
a broadcast address of an anycast
group.
14
40315
SNTP Update
Interval
300
1…32766
• •
• • •
Indicates how often the time is updated
from the SNTP Server. The unit is
minute.
15
40316
Time Zone Select
7
0…32
• •
• • •
The time zone table has detailed time
zone information.
16
40317
Time Server IP
Address Byte a
0
0…255
• •
• • •
The internal clock is set after each Time
set interval has expired. The Time server
IP address is the SNTP time server
where the request is handled.
17
40318
Time Server IP
Address Byte b
0
0…255
• •
• • •
The internal clock is set after each Time
set interval has expired. The Time server
IP address is the SNTP time server
where the request is handled.
18
40319
Time Server IP
Address Byte c
0
0…255
• •
• • •
The internal clock is set after each Time
set interval has expired. The Time server
IP address is the SNTP time server
where the request is handled.
Ethernet Configuration
Element
No.
Modbus
Address
Element Name
Default
Value
Range
TR1
TR2
EM1
EM2
EM3
Description
