Max Power . . . . . . . . . . . . . The relay will activate when the Output Power is
equal to the Max Power value and deactivate when
the Output Power is below the Max Power value.
Time Setpoint . . . . . . . . . . The relay will activate when the Time End Point
value is reached.
Thickness Setpoint . . . . . . The relay will activate when the Thickness End Point
value is reached.
Final Thickness . . . . . . . . . The relay will activate when the Final Thickness
value is reached.
All Crystals Good . . . . . . . The relay will activate when all activated sensors
have valid frequency readings.
All Crystals Fail . . . . . . . . . The relay will activate when none of the activated
sensors has a valid frequency reading.
Test pane
The PLC relays can be tested without starting a Process. Select a relay event in
the Test box that matches the relay event assigned to the relay to be tested. Use
the Set, Clear, and Clear All commands to test the relay.
Set . . . . . . . . . . . . . . . . . . . . Activates the relay(s) corresponding to the selected
event.
Clear . . . . . . . . . . . . . . . . . . Deactivates the relay(s) corresponding to the
selected event.
Clear All . . . . . . . . . . . . . . . Deactivates all activated relays.
Input Events pane
Selecting an event from an Input Events box will initiate this event when the
corresponding PLC input is activated.
Not Assigned . . . . . . . . . . . Activating the corresponding PLC input has no effect
on events.
Start Process . . . . . . . . . . . Starts the current Process.
Abort Process . . . . . . . . . . Aborts the current Process.
Start Layer . . . . . . . . . . . . . Starts the current Layer.
Stop Layer. . . . . . . . . . . . . . Stop the current Layer.
Next Layer. . . . . . . . . . . . . . Skips the current Layer and starts the next Layer.
Force Final Thick . . . . . . . . Same effect as reaching the Final Thickness value.
Zero Thickness. . . . . . . . . . Zeroes the Thickness reading.
Zero Time (NA) . . . . . . . . . . This event is not available.
