IQS-233 Operating Manual
Events to Log pane
End Deposit Phase. . . . . . . . . . . . . Data is recorded at the end of each layer’s
deposit phase.
End Each Phase . . . . . . . . . . . . . . . Data is recorded at the end of all phases.
I/O Events . . . . . . . . . . . . . . . . . . . . Data is recorded each time an external digital
input or output changes state.
Timed. . . . . . . . . . . . . . . . . . . . . . . . Data is recorded at the selected time interval.
Sensors . . . . . . . . . . . . . . . . . . . . . . Data is recorded for individual sensors in
addition to the normally recorded data.
Readings (yymmdd.log) . . . . . . . . When the Readings check box is selected,
the following data from individual sensors is
recorded and saved in a separate file: Timer,
Run Time, Sensor #, Rate, Thickness, and
Frequency. The file is saved in the format of
yymmdd.csv (for example, data saved on
January 15, 2014 will be saved to a file
named 140115.csv).
2.3.3.2 Print Process
Click File >> Print Process to print the configuration parameters for the current
Process to the default printer.
2.3.3.3 User Login
Click File >> User Login to display the User Login window (see
allowing a different user to log on to IQS-233 Codepostion software. When a
different User name and its associated Password are entered, the current session
is ended and the security access levels change to that of the new user. See
for more information.
Figure 2-13 User Login window
