IQM-233 Operating Manual
3.3.4.7 Current Configuration File
The name of the currently used configuration file is displayed on the menu bar (see
Figure 3-27 ). The Config.xml configuration file, containing the factory-default
software configuration parameters, is automatically loaded when the IQM-233
Standard software is started. Other previously saved configuration files can then be
loaded using File >> Load (refer to
section 3.3.3.4, File, on page 3-17 ).
Figure 3-27 Configuration file
CAUTION
If the Config.xml file is not found by the IQM-233 software
upon starting, an error will occur and the software will
close. Do not move this file to another folder location or
change the name of this file.
NOTE: Initially, the Config.xml file contains factory-default parameter values;
however, the factory-default parameter values can be overwritten if
changes are made to the parameter values and the new values are saved
to the Config.xml file, either by using File >> Save (refer to
section
3.3.3.4, File, on page 3-17 ), or by selecting the check box next to Save any
changes to Config.xml upon exiting the IQM-233 Standard software (see
section 3.3.4.8 ).
3.3.4.8 Exit Window
When exiting the IQM-233 Standard software, changes made to the current
configuration parameter values can be saved by selecting the Save any changes
to (name).xml check box and clicking Yes. See
Figure 3-28 .
Figure 3-28 Exit window - Save any changes
