Page 247

10-19
6036, 6042, 8042, 10042, 10054
Stabil-TRAK™
System and Boom Interlock System
Note: If an outrigger is raised or a pressure switch is
defective, boom on the 10054 will not extend beyond the
42 Series extension limit.
Definitions:
Boom Retracted = Less than 42 Series extension limit
Boom Extended = Boom at 42 Series extension limit or
greater (See Figure at Right).
PB = Park Brake
DE = De-energized
E = Energized
C = Closed
O = Open
H
G
F
E
D
C
B
A
42
S
er
ie
s
Ex
te
ns
io
n L
im
it
MH6110
