Electrical System
9-32
6036, 6042, 8042, 10042, 10054
141
100
4
Amber
Engine Oil
Pressure
Oil Pressure Sensor Circuit—Voltage Below Normal, or
Shorted to Low Source
143
100
18
Amber
Engine Oil
Pressure
Oil Pressure Low—Data Valid but Below Normal Operational
Range—Moderately Severe Level
415
100
1
Red
Engine Oil
Pressure
Oil Pressure Low – Data Valid but Below Normal Operational
Range - Most Severe Level
435
100
2
Amber
Engine Oil
Pressure
Oil Pressure Sensor Circuit - Data Erratic, Intermittent, or
Incorrect
555
101
16
Amber
Not Available
Crankcase Pressure—Data Valid But Above Normal Operating
Range—Moderately Severe Level
556
101
0
Red
Not Available
Crankcase Pressure—Data Valid But Above Normal Operating
Range—Moderately Severe Level
1843
101
3
Amber
Not Available
Crankcase Pressure Circuit—Voltage Above Normal, or
Shorted to High Source
1844
101
4
Amber
Not Available
Crankcase Pressure Circuit—Below Normal, or Shorted to
Low Source
1942
101
2
Amber
Not Available
Crankcase Pressure—Data Erratic, Intermittent or Incorrect
1974
101
15
Amber/
Blinking
Not Available
Crankcase Pressure—Data Valid But Above Normal Operating
Range—Least Severe Level
122
102
3
Amber
Boost
Pressure
Intake Manifold Pressure Sensor Circuit—Voltage Above
Normal, or Shorted to High Source
123
102
4
Amber
Boost
Pressure
Intake Manifold Pressure Sensor Circuit—Voltage Below
Normal, or Shorted to Low Source
2973
102
2
Amber
Boost
Pressure
Intake Manifold Pressure Sensor Circuit—Data Erratic,
Intermittent, or Incorrect
595
103
16
Amber
Turbocharger
1 Speed
Turbocharger #1 Speed High - Data Valid but Above Normal
Operational Range—Moderately Severe Level
687
103
18
Amber
Turbocharger
1 Speed
Turbocharger #1 Speed Low—Data Valid but Below Normal
Operational Range—Moderately Severe Level
2288
103
15
None
Not Available
Turbocharger 1 Speed—Data Valid But Above Normal
Operating Range—Least Severe Level
Fault
Code
SPN
Code
FMI
Code
LAMP
Area
Description
Diagnostic Description
