10-11
6036, 6042, 8042, 10042, 10054
Stabil-TRAK™
System and Boom Interlock System
10.7
STABIL-TRAK™
SYSTEM TEST
Note: The operator must know that the Stabil-TRAK™
system is active and functioning properly.
To test the function of the Stabil-TRAK™
system, read
the Stabil-TRAK™
System Test instructions and follow
Steps 1 through 9 of Section 10.7.2, “Stabil-TRAK™
System Test Procedures.”
10.7.1
Stabil-TRAK™
System Test
Instructions
• Test the Stabil-TRAK™
system with the vehicle
on a level surface.
• Remove any attachment from the quick attach
before performing the test.
• DO NOT extend the boom at any time during the
test. Perform the test with the boom fully retracted.
• DO NOT raise the boom above 60° for Steps 3-6.
• DO NOT raise the boom above 45° for Steps 7-9.
• Follow Steps 1 through 9 of the Stabil-TRAK™
system test procedure exactly as written.
Note: If the Stabil-TRAK™
light goes OFF and the front
left tire lowers to the ground at any time during Steps 4
through 7, the test was not performed properly or the
Stabil-TRAK™
system is not functioning properly.
Carefully repeat the steps starting with Step 1.
If Stabil-TRAK™
light goes OFF and front left tire lowers
to ground consistently during Steps 4 through 7, the
Stabil-TRAK™
system is not functioning properly and test
should be stopped immediately. If the Stabil-TRAK™
system is not functioning properly, follow the procedures
in Section 10.11, “Stabil-TRAK™
Hydraulic Circuit
Operation and Troubleshooting,” to repair the system.
10.7.2
Stabil-TRAK™
System
Test Procedures
If Steps 1 through 9 prove positive, the Stabil-TRAK™
system is functioning properly, and vehicle can be
returned to service. If any of these steps indicate that the
Stabil-TRAK™
system is not functioning properly, follow
procedures in Section 10.11, “Stabil-TRAK™
Hydraulic
Circuit Operation and Troubleshooting,” to repair system.
