Electrical System
9-36
6036, 6042, 8042, 10042, 10054
1117
627
2
None
Power Supply
Power Lost With Ignition On—Data Erratic, Intermittent,
or Incorrect
343
629
12
Amber
Controller #1
Engine Control Module Warning internal hardware failure - Bad
Intelligent Device or Component
2311
633
31
Amber
Fuel Control
Valve #1
Fueling Actuator #1 Circuit Error—Condition Exists
285
639
9
Amber
SAE J1939
Datalink
SAE J1939 Multiplexing PGN Timeout Error—Abnormal
Update Rate
286
639
13
Amber
SAE J1939
Datalink
SAE J1939 Multiplexing Configuration Error—Out of
Calibration
599
640
14
Red
Engine
External
Protection
Input
Auxiliary Commanded Dual Output Shutdown—
Special Instructions
237
644
2
Amber
External
Speed Input
External Speed Input (Multiple Unit Synchronization)—Data
Erratic, Intermittent, or Incorrect
245
647
4
Amber
Fan Clutch
Output Device
Driver
Fan Control Circuit—Voltage Below Normal, or Shorted to Low
Source
2377
647
3
Amber
Fan Clutch
Output Device
Driver
Fan Control Circuit—Voltage Above Normal, or Shorted to
High Source
322
651
5
Amber
Injector
Cylinder #01
Injector Solenoid Cylinder #1 Circuit – Current Below Normal,
or Open Circuit
331
652
5
Amber
Injector
Cylinder #02
Injector Solenoid Cylinder #2 Circuit – Current Below Normal,
or Open Circuit
324
653
5
Amber
Injector
Cylinder #03
Injector Solenoid Cylinder #3 Circuit – Current Below Normal,
or Open Circuit
332
654
5
Amber
Injector
Cylinder #04
Injector Solenoid Cylinder #4 Circuit – Current Below Normal,
or Open Circuit
584
677
3
Amber
Starter
Solenoid
Lockout Relay
Driver Circuit
Starter Relay Driver Circuit—Voltage Above Normal, or
Shorted to High Source
527
702
3
Amber
Circuit—
Voltage
Auxiliary Input/Output 2 Circuit—Voltage Above Normal, or
Shorted to High Source
529
703
3
Amber
Circuit—
Voltage
Auxiliary Input/Output 3 Circuit—Voltage Above Normal, or
Shorted to High Source
Fault
Code
SPN
Code
FMI
Code
LAMP
Area
Description
Diagnostic Description
