Electrical System
386
3509
3
Amber
5 Volts DC
Supply
Sensor Supply Voltage #1 Circuit – Voltage Above Normal, or
Shorted to High Source
187
3510
4
Amber
5 Volts DC
Supply
Sensor Supply Voltage #2 Circuit—Voltage Below Normal, or
Shorted to Low Source
227
3510
3
Amber
5 Volts DC
Supply
Sensor Supply Voltage #2 Circuit—Voltage Above Normal, or
Shorted to High Source
238
3511
4
Amber
System
Diagnostic
code # 1
Sensor Supply Voltage #3 Circuit—Voltage Below Normal, or
Shorted to Low Source
239
3511
3
Amber
System
Diagnostic
code #2
Sensor Supply Voltage #3 Circuit—Voltage Above Normal, or
Shorted to High Source
2185
3512
3
Sensor Supply 4 Circuit—Voltage above normal, or shorted to
high source
1695
3513
3
Amber
Not Available
Sensor Supply 5—Voltage Above Normal, or Shorted to
High Source
1696
3513
4
Amber
Not Available
Sensor Supply 5—Voltage Below Normal, or Shorted to
Low Source
515
3514
3
Amber
Not Available
Sensor Supply 6 Circuit—Voltage above normal, or shorted to
high source
516
3514
4
Amber
Not Available
Sensor Supply 6 Circuit—Voltage below normal, or shorted to
low source
1938
3597
18
Amber
Not Available
ECU Power Output Supply Voltage 1—Data Valid But Below
Normal Operating Range—Moderately Severe Level
1939
3597
3
Amber
Not Available
ECU Power Output Supply Voltage 1—Voltage Above Normal,
or Shorted to High Source
1941
3597
4
Amber
Not Available
ECU Power Output Supply Voltage 1—Voltage Below Normal,
or Shorted to Low Source
3139
3667
3
Amber
Engine Air Shutoff Circuit—Voltage above normal, or shorted
to high source
3141
3667
4
Amber
Engine Air Shutoff Circuit—Voltage below normal, or shorted
to low source
3918
5421
13
Amber
Engine Turbocharger Wastegate Actuator—Out of Calibration
Fault
Code
SPN
Code
FMI
Code
LAMP
Area
Description
Diagnostic Description
