Stabil-TRAK™
System and Boom Interlock System
Step 7
a. With the parking brake switch ON, move the travel select lever to the (N) NEUTRAL position.
b. Lower the boom to exactly 45°.
c. Frame level the vehicle no more than 5° to the left.
d. Frame level the vehicle back to 0°.
e. Frame level the vehicle no more than 5° to the right.
Note: Observe that frame level will be slower than normal during this test.
f. The Stabil-TRAK™
light should remain ON and the front left tire should remain off the ground. The
front left tire should not raise or lower during frame level.
g. Frame level back toward 0°, leaving the vehicle leveled to the right approximately 1° to 2°.
Step 8
a. Depress the service brake pedal.
b. Disengage the parking brake switch.
c. With the range select lever in (1) FIRST gear, move the travel select lever to the (R) REVERSE
position.
d. Release the service brake pedal to deactivate the Stabil-TRAK™
system.
e. The Stabil-TRAK™
light should go OFF.
f. The front left tire should return to the ground while the vehicle travels in reverse.
g. Depress the service brake pedal to stop the vehicle.
Step 9
a. With the service brake pedal depressed and the boom angle exactly 45° move the range select
lever to (3) THIRD gear.
b. Move the travel select lever to (F) FORWARD.
c. Release the service brake pedal to deactivate the Stabil-TRAK™
system. The Stabil-TRAK™
light
should go OFF.
d. Slowly drive the vehicle forward against the block to stop the vehicle from moving forward.
e. With the front left tire against the block, frame level the vehicle no more than 5° to the left.
f. Check that front left tire remains on ground. It is normal for front left tire to raise slightly when
leveling to left, but tire should immediately lower when frame level function is stopped.
g. Frame level the vehicle back to 0° and pause briefly.
h. Frame level the vehicle no more than 5° to the right.
i. Check that the front right tire remains on the ground. It is normal for the front right tire to raise
slightly when leveling to the right, but the tire should immediately lower when the frame level function
is stopped.
j. Frame level the vehicle back to 0°.
k. Depress the service brake pedal.
l. Shift the travel select lever to (N) NEUTRAL.
m. Lower the boom.
Stabil-TRAK System Test Procedures
