8-35 6036, 6042, 8042, 10042, 10054
Hydraulic System
8.8.4 Cylinder Torque Specifications
a. Lift/Lower Cylinder
b. Extend/Retract Cylinder
c. Tilt Cylinder
d. Level Cylinder
e. Stabil-TRAK Cylinder
Model Nut Valve Locking Collar
6036, 6042 1750-2000 lb-ft
(2373-2712 Nm)
30-35 lb-ft
(41-47 Nm)
300-400 lb-ft
(407-542 Nm)
8042, 10042, 10054 1735-1885 lb-ft
(2352-2556 Nm)
30-35 lb-ft
(41-47 Nm)
300-400 lb-ft
(407-542 Nm)
Model Head Piston Valve Set Screw
6036 300-400 lb-ft
(407-542 Nm)
300-400 lb-ft
(407-542 Nm)
45-50 lb-ft
(61-68 Nm)
12-13 lb-ft
(18-19 Nm)
6042 300-400 lb-ft
(407-542 Nm)
330-390 lb-ft
(447-529 Nm)
40-50 lb-ft
(54-67 Nm)
10-26 lb-ft
(13-35 Nm)
8042, 10042, 10054 300-400 lb-ft
(407-542 Nm)
390-460 lb-ft
(529-624 Nm)
150-160 lb-ft
(1203-217 Nm)
9-11 lb-ft
(12-15 Nm)
Model Head Piston Locknut Locking
Collar
Valve Set Screw
6036, 6042 300-400 lb-ft
(407-542 Nm)
200-300 lb-ft
(271-407 Nm)
N/A N/A 30-35 lb-ft
(41-47 Nm)
30-35 lb-ft
(41-48 Nm)
8042, 10042,
10054
N/A N/A 1735-1885 lb-ft
(2352-2556 Nm)
300-400 lb-ft
(407-542 Nm)
30-35 lb-ft
(41-47 Nm)
N/A
Head Locknut Valve
300-400 lb-ft (407-542 Nm) 1100-1250 lb-ft (1491-1695 Nm) 35-40 lb-ft (47-54 Nm)
Model Locknut Check Valve Guide Set Screw Pressure
Reducing/
PO Check
Valve
Solenoid
Coil
6042 1175-1400 lb-ft
(1593-1898 Nm)
20-25 lb-ft
(27-34 Nm)
300-350 lb-ft
(407-475 Nm)
3-4 lb-ft
(4-5 Nm)
35-40 lb-ft
(47-54 Nm)
25-30 lb-ft
(34-41 Nm)
8042, 10042,
10054
N/A 20-25 lb-ft
(27-34 Nm)
300-350 lb-ft
(407-475 Nm)
3-4 lb-ft
(4-5 Nm)
35-40 lb-ft
(47-54 Nm)
25-30 lb-ft
(34-41 Nm)
