Brocade ICX 6650 Administration Guide 219
53-1002600-01
LLDP-MED attributes advertised by the Brocade device
8
Syntax: show lldp
The following table describes the information displayed by the show lldp statistics command.
Displaying LLDP statistics
The show lldp statistics command displays an overview of LLDP neighbor detection on the device,
as well as packet counters and protocol statistics. The statistics are displayed on a global basis.
The following shows an example report.
Field Description
LLDP transmit interval The number of seconds between regular LLDP packet transmissions.
LLDP transmit hold
multiplier The multiplier used to compute the actual time-to-live (TTL) value of an LLDP
advertisement. The TTL value is the transmit interval multiplied by the transmit hold
multiplier.
LLDP transmit delay The number of seconds the LLDP agent will wait after transmitting an LLDP frame and
before transmitting another LLDP frame.
LLDP SNMP notification
interval The number of seconds between transmission of SNMP LLDP traps
(lldpRemTablesChange) and SNMP LLDP-MED traps
(lldpXMedTopologyChangeDetected).
LLDP reinitialize delay The minimum number of seconds the device will wait from when LLDP is disabled on a
port, until a request to re-enable LLDP on that port will be honored.
LLDP-MED fast start
repeat count The number of seconds between LLDP frame transmissions when an LLDP-MED
Endpoint is newly detected.
LLDP maximum
neighbors The maximum number of LLDP neighbors for which LLDP data will be retained, per
device.
LLDP maximum
neighbors per port The maximum number of LLDP neighbors for which LLDP data will be retained, per port.
