158
Brocade ICX 6650 Administration Guide
53-1002600-01
SNMP community strings
6
The command in this example associates the view “sysview” to the community string named
“myread”. The community string has read-only access to “sysview”. For information on how to
create views, refer to
“SNMP v3 configuration examples”
The
which ACL group will be used to filter incoming SNMP packets. You can enter either the ACL name
or its ID. Here are some examples.
Brocade(config)#snmp-s community myread ro view sysview 2
Brocade(config)#snmp-s community myread ro view sysview myACL
The command in the first example indicates that ACL group 2 will filter incoming SNMP packets;
whereas, the command in the second example uses the ACL group called “myACL” to filter incoming
packets.Refer to the Brocade ICX 6650 Switch Security Configuration Guide for more information.
NOTE
To make configuration changes, including changes involving SNMP community strings, you must
first configure a read-write community string using the CLI. Alternatively, you must configure another
authentication method and log on to the CLI using a valid password for that method.
Displaying the SNMP community strings
To display the configured community strings, enter the following command at any CLI level.
Syntax: show snmp server
NOTE
If display of the strings is encrypted, the strings are not displayed. Encryption is enabled by default.
Brocade#show snmp server
Contact: Marshall
Location: Copy Center
Community(ro): public
Community(rw): private
Traps
Cold start: Enable
Link up: Enable
Link down: Enable
Authentication: Enable
Locked address violation: Enable
Power supply failure: Enable
Fan failure: Enable
Temperature warning: Enable
STP new root: Enable
STP topology change: Enable
ospf: Enable
Total Trap-Receiver Entries: 4
Trap-Receiver IP Address Community
1 192.95.6.211
2 192.95.5.21
