The Triggers
47
Figure 94: Select the Behavior of the Digital Input Trigger
You can now add actions to this trigger (see Section 6.2
6.9 The Button Trigger
).
A button trigger is created when a selected button is pressed.
To create a button trigger, do the following:
1. In the Control Room tree, select the machine to which you want to assign a button trigger
1 (for
example, the RC-63A):
Figure 95: Selecting the Device from the Control Room List
2. Click a button from the Device View to which you want to assign a trigger (for example, button 2):
Figure 96: Selecting a Button
The button’s frame color changes and the Button Trigger Properties window appears:
1 Applicable buttons are colored light blue
