KRAMER: SIMPLE CREATIVE TECHNOLOGY
Tab Area Settings
22
5.1.1 Defining the Ethernet Ports
The Ethernet ports let you send serial commands via the Ethernet port to up to three IP addresses
located on the same subnet.
To define an Ethernet port, do the following
1. Set the Ethernet port Driver and Description.
2. Click the Properties field to define the Ethernet settings:
Figure 33: Ethernet Settings Example
3. The Ethernet port appears in the Port Command list and can be used to send any commands or
triggers to the device.
Figure 34: Ethernet Port in the Port Command List
Figure 35: Ethernet Port in the Port Command List (Select Command)
