CLR−...
Festo CLR−... 0912d English
34
13
Technical specifications
CLR−...
12
16
20
25
32
40
50
63
Design
Double−acting pneumatic cylinder with swivel
mechanism
Mounting position
As desired
Medium
Filtered compressed air, lubricated or non−lubricated
(filter fineness 40 Ģm)
Operating pressure range
2 ... max. 10 bar
Connecting thread
M5
G 1/8
Temperature range
−10 ... +80 °C
(ambient)
−10 ... +50 °C
(storage)
Theoretical tension force [N]
Effective tension force [N]
(at 6 bar returning)
51
34
90
53
121
109
227
188
362
313
633
536
990
716
1682
1386
Possible swivel direction
L/R
L/R/G
(L = left, R = right, G = straight)
Max. perm. work frequency
(at room temperature)
Ĉ Linear−swivel movement:
0.8 Hz
Ĉ Linear movement:
1 Hz
Max. swivel angle tolerance
90° ±4°
90° ±3°
90° ±2°
Stroke tolerance
0 mm /+2.5 mm
Materials
Housing:
Al
Piston rod:
St (coated with CLR−...−K11−R8)
Collar screws, guide pin:
St
Bearings:
CuSn
Seals:
NBR, TPR
Wiper (with CLR−...−K11−R8):
PPS
Weight without clamping
finger [kg] (approx.)
Ĉ at 10 mm stroke
Ĉ at 20 mm stroke
0.14
0.16
0.16
0.19
0.34
0.39
0.40
0.46
0.69
0.77
0.88
0.99
1.7
2.1
2.1
2.7
Fig. 25
