CLR−...
Festo CLR−... 0912d English 33
12 Trouble−shooting
Fault Cause Possibilities
Swivel and clamping
sequence not expected Guide bolt in wrong groove Modification to the swivel
movement see chapter
Mechanical installation"
Proximity switch does
not switch Ferritic objects in vicinity
(fastening elements) Use non−ferritic materials or a
different type of proximity
switch (SMT−8−...)
Hard impact at the end
positions Mass on clamping finger
too large / non−permitted
parts used Use clamping finger with
unmodified clamping screw
Excessive speed Restrict swivel motion more
CLR−... cannot hold the
part to be clamped Insufficient operating
pressure Increase operating pressure
to maximum permitted value
Fig. 24
