Battery – Samsung SGH-T989ZKBTMB User Manual
Page 17
Installing Battery
Removing Battery
Removing the microSD Memory Card
Removing the Battery
1. Remove the battery cover.
� Grip the battery at the top end (3) and lift it up and out
of the battery compartment (4).
2. Firmly press the card into the slot and release it. The
card should pop partially out of the slot.
3. Remove the card from the slot.
4. Replace the battery cover.
Battery
Before using your device for the first time, install the battery
and charge it fully.
Important! Before removing or replacing the battery, make
sure the device is switched off. To turn the device
off, hold down the
key until the Device
options screen displays, then tap Power off.
Installing the Battery
1. Slide the battery into the compartment (1) so that the
tabs on the end align with the slots at the bottom of the
phone, making sure the connectors align.
2. Gently press down to secure the battery (2).
Getting Started 12
