2004.06.28 CHAPTER 1: Using DelphNav™ (Survey Control Panel) 47
Using Delph Nav Data Display Windows
Note: The color of the vessel track should indicate the status of recording (red for no
recording, blue for recording).
All navigation files may be played back in DelphNav through selecting the Files tab
option of the Survey Planning window, opening the relevant XTF files, and selecting the
Play button. Options affecting the playback of such files appear in the Settings dialog box
shown in Figure 26 on page 46.
Data Display Windows
DelphNav provides a number of display windows for conducting quality control on
incoming data strings, in addition to the Helmsman Display window that can be used to
assist steering along a survey line. Each of these display windows will be presented in
detail in the following sections.
Single Beam Profile Display
The Single Beam Profile Display window (Figure 27) is capable of showing up to two
different sources of sounding data (for example, two different frequencies of an echo
sounder).
