2004.06.28 CHAPTER 1: Using DelphNav™ (Survey Control Panel) 9
Using Delph Nav Serial Server
FIGURE 5. Serial Server GUI minimized as icon in system tray
If the GUI is minimized in the System Tray (Figure 5), left-clicking the icon restores the
serial server dialog box. Right-clicking the icon enables you to make changes to the serial
setup without restoring the full dialog box.
Special Considerations for Working with Serial Server
As of the Fall 2000 release of TEI software, SERIALSRV.EXE is installed in a folder
called C:\{Windows Folder}\TEIdlls, where {Windows Folder} is the main
folder for the Microsoft Windows operating system (Windows 95, NT, 2000, etc.).
Once the path to the server has been chosen during startup and the serial server has been
started, two INI files are created: SERIALSRV.INI and SERIALDLL.INI. These files
can be found in the C:\{Windows Folder}.
If a previous version of SERIALSRV.EXE has been started from some place other than
C:\{Windows Folder}\TEIdlls, then one of two error messages is likely to occur:
“SERIALDLL.DLL was previously loaded from an unexpected folder.”
or
“Server Launch FAIL: Launch it manually.”
Other Error Messages
If your computer system finds certain older copies of some TEI DLLs, other error mes-
sages can result. For example, you might see the message, Missing Entry Points
in Dynamic Link Library
. In general, the solution to all these problems is as fol-
lows:
