1.

From the System tab in the scenario editor, click the check box preceding the virtual system(s)
that you want to move. You must include at least two VM hosts. One from which you will be
moving the VMs, and one to which you will be moving the VMs.

2.

Select What-if Action

→Move Virtual Machines... from the menu bar.

The Edit Scenario: Move Virtual Machines screen displays.

3.

Change the Meter Style, if desired.

4.

Change the Data Range if a different size of data collection is desired, and click OK to refresh
the table display.

TIP:

A longer data collection period provides a better picture of activity on the system over

time than shorter periods do.

5.

Change the Meters Represent setting if a different calculation is desired .

6.

The first table presents the virtual machines selected for the move.

7.

Optional. Change the headroom calculation. You must click Refresh to update the server
destination table with the new values.

8.

Within the table titled To: (Selected VM Host), select a destination VM host for the previously
selected systems. The OK button becomes enabled for use.

Server presentation:

The table entries are ordered by

headroom fitness

as determined by Capacity Advisor, and

Capacity Advisor selects the top selection by default. Examine the headroom rating and the
utilization meters for each prospective host to determine which host best fits your goals for
headroom fitness and optimal utilization.

9.

Click OK to accept these changes.

Unknowingly accepting unseen values:

This can happen if you modify the headroom calculation after selecting the destination server,
but then click OK without refreshing the destination table with the new values. The resulting
change to the utilization values shown in the System tab view will differ from those seen in
the previously shown destination table because the System tab will reflect the modified values.

When modifying headroom, remember to click Refresh, and check the updated values shown
in the utilization meters in the destination table. Once you have refreshed this table, select a
server based on the new values. If you want the same server that you selected before changing
the values, you must re-select that server to enable the OK button.

The System tab of the Edit Scenario screen opens showing the new virtual machine relationships.

Removing a system

As your scenarios evolve, you might need to remove systems from a scenario to represent planned
or actual changes.
1.

From the System tab of the scenario editor, click in the check boxes beside the systems that
you want to remove from the scenario.

2.

Select Edit

→Remove Systems... from the menu bar.

A confirmation screen listing the systems you are removing will be presented.

3.

Click the OK button.

You will be returned to the Capacity Advisor - Edit Scenario screen with the systems you selected
removed.

Working with systems

99
