Working with power

When you are calibrating power data settings, you specify the following:

how power metrics should be displayed for graphs, meters, and reports

how the power estimation should be calibrated:

manually (you specify idle/maximum watt usage)

automatically (using power and CPU data obtained from Insight Control power
management and HP Integrated Lights-Out

none (no power metrics are displayed)

Power settings can be calibrated for actual systems from the Matrix OE visualization screen and
for simulated systems from within a Capacity Advisor scenario. These two areas are discussed in
the sections below.

TIP:

The various power calibration screens look similar to one another, but you can tell that you

are within a scenario rather than interacting with the actual system when the screen title includes
the words Edit Scenario:.

IMPORTANT:

For specific descriptions of each field or summary table on the user interface

screens, click the help topic link

on the software screen for the task.

TIP:

For lists of all menu options for Capacity Advisor features, see “Menus & tabs” in Capacity

Advisor Help.

Calibrating power on actual systems

This screen allows you to directly calibrate the power settings for actual managed systems. You
can specify the source data for the power metrics that are stored on the system and displayed in
the profile viewers available from the power meter displays on the Visualization tab. Collected
power data is also viewable in

historic resource utilization reports

.

All power calibration options (manual, automatic, none) are available from the Matrix OE
visualization screen. The resulting calculated metrics are viewable in the power measurements and
graphs on the Visualization tab.

Insight Control power management and Integrated Lights-Out

If you choose to use power data from Power Management , you will be interacting with Insight
Control power management and Integrated Lights-Out on the system itself. Therefore, you will need
appropriate authorizations for the target systems. For more information, see following Internet
locations:

Insight Control power management

HP Integrated Lights-Out

Prerequisites

You will need “VSE All Tools” permissions on the managed systems where you want to calibrate
power. (See

“Accessing Capacity Advisor” (page 59)

.)

Procedure 31 Open the Visualization tab

1.

Select (Tools

→HP Matrix OE visualization)

The Visualization tab opens.

2.

View the list of systems in the display.

Working with power 105
