Ccx number of points 2, Ccx point pair 01 0 --> 0 – West Control Solutions MRC 9000 User Manual
Page 99

Edition 3
Rev G
Section 4
4-17
4. Press the
to advance to the next parameter, NUMBER OF POINTS.
5. Press the
to advance to the next parameter, POINT PAIR 01 .
Press the
to change, then
to select digit to change, then
to desired digit, then
press the
. This will change the "input" value (left number). Then change the "output" value
(right number) and then press the
.
6. Press the
to advance to the next parameter, POINT PAIR 02.
Follow the same procedure as in step 5 (above) to choose your selections.
C
U
S
T
O
M
C
U
R
V
E
S
Press the
to change, then
to
desired number, then press the
.
CCx POINT PAIR 01
0 --> 0
Selections
±
999999
(decimal position = 0)
±
9.9999
(decimal position = 4)
Selections
±
999999
(decimal position = 0)
±
9.9999
(decimal position = 4)
CCx POINT PAIR 02
100 --> 100
Selections
±
999999
(decimal position = 0)
±
9.9999
(decimal position = 4)
Selections
±
999999
(decimal position = 0)
±
9.9999
(decimal position = 4)
CCx NUMBER OF POINTS
2
Selections
2 to 21
