Cx out 1 hysteresis 3 units, Cx out 2 hysteresis 3 units, Cx out 1 percent upper limit 100 – West Control Solutions MRC 9000 User Manual

Page 237

Section 13

Edition 3
Rev G

13-6

6. Press the

to advance to the next parameter, OUTPUT 1 HYSTERESIS

(only seen if OUT 1 TYPE is ON/OFF).

NOTE: Units correspond to
Units configured in Process
Variables

Cx OUT 1 HYSTERESIS

3 UNITS

Selections

0 to 999999

(decimal position = 0)

0 to 9.9999

(decimal position = 4)

7. Press the

to advance to the next parameter, OUTPUT 2 HYSTERESIS (only seen if OUT 2 TYPE is ON/

OFF).

NOTE: Units correspond to
Units configured in Process
Variables

Cx OUT 2 HYSTERESIS

3 UNITS

Selections

0 to 999999

(decimal position = 0)

0 to 9.9999

(decimal position = 4)

8. Press the

to advance to the next parameter, OUTPUT 1 PERCENT UPPER LIMIT (only seen if OUT 1

TYPE is PID).

Cx OUT 1 PERCENT

UPPER LIMIT 100%

Selections

1 to100

Press the

to change, then

to desired number, then press the

Note: Hysteresis centers on the control setpoint.

Press the

to change, then

to desired choice, then press the

Press the

to change, then

to desired number, then press the

Note: Hysteresis centers on the control setpoint.
