Section 4

Edition 3
Rev G

4-10

19. If V/mA conversion selected was EXP, press the

to advance to the next parameter, EXPONENT.

20. Press the

to advance to the next parameter, CUTOFF TYPE.

21. If CUTOFF TYPE selected was other than NONE, press the

to advance to the next parameter,

CUTOFF VALUE.

Press the

to change, then

to

desired value, then press the

.

IVx EXPONENT

1.500

Selections

0.000 to 5.000

IVx VALUE CUTOFF TYPE

NONE

Selections

NONE AT VALUE

TO ZERO BELOW VALUE

TO ZERO NEAR ZERO

I

N

P

U

T

S

Press the

to change, then

,

to desired choice, then press the

.

Press the

to change, then

,

to desired value, then press the

.

Units correspond to
units configured in step
14 or 15.

IVx CUTOFF VALUE

0 units

Selections

±

999999

(decimal position = 0)

±

9.9999

(decimal position = 4)
