Functions – West Control Solutions Pro-16 User Manual
Page 77

Special
functions
9499-040-93811 / 59537-1
Page 77 of 88
Pro-16
9.5.3
Starting the timer
Dependent of configuration, the timer start is as follows:
by a positive activation at one of digital inputs di1..3
by switching on the manual mode via
è
- key
by switching on the controller (power On)
by changing the timer run-time
t.ti > 0 (extended operating level)
via the serial interface
Display:
run-LED
Signification
blinks
timer was started
timer is not running yet
lit
timer was started
timer is running
off
timer is off
(
End and setpoint are
timer has elapsed
displayed alternately)
deletion of
End
display by
pressing any key
g
With active timer, the time can be adjusted by changing parameter t.ti at extended
operating level.
