Parameter-Level

9499-040-93811 / 59537-1

Page 54 of 88

Pro-16

HYS.L 0...9999

Switching difference Low signaller [engineering unit]

1

HYS.H 0...9999

Switching difference High signaller [engineering unit]

1

d.SP -1999...9999 Trigger point seperation for additional contact  / Y / Off

[phys. dimensions]

100

tP

0,1...9999 Minimum impulse [s]

OFF

tt

3...9999

Motor travel time [s]

60

Y2

-100...100 2. correcting variable

0

Y.Lo -105...105 Lower output limit [%]

0

Y.Hi -105...105 Upper output limit [%]

100

Y.0

-100...100 Working point for the correcting variable [%]

0

Ym.H -100...100 Limitation of the mean value Ym [%] (see

Fail

page 28)

5

L.Ym

0...9999

Max. deviation xw at the start of mean value calculation

[phys. dimensions]

8

E.H2O -1999...9999 Min. temperature for water cooling. Below the set

temperature no water cooling happens.

120

t.on 0,1...9999 Impulse lenght for water cooling. Fixed for all values of

controller output.The pause time is varied.

0,1

t.oFF 1...9999

Min. pause time for water cooling. The max. effective
controller output results from t.on/(

t.on

+

t.off

)·100%

2

F.H2O 0,1...9999 Modification of the (non-linear) water cooling characteristic

(see page 44)

0,5


1

Valid for

ConF/ othr/ DP = 0. With DP = 1/ 2/ 3 also 0,1 / 0,01 / 0,001.

PAr.2

Name

Value range Description

Default

Pb12 1...9999 1 Proportional band 1 (heating) in phys. dimensions (e.g. °C),

2. parameter set

100

Pb22 1...9999 1 Proportional band 2 (cooling) in phys. Dimensions (e.g. °C),

2. parameter set

100

Ti12 OFF/0,1...9999 Integral action time 2 (cooling) [s], 2. parameter set

180

Ti22 OFF/0,1...9999 Integral action time 1 (heating) [s], 2. parameter set

180

Td12 OFF/0,1...9999 Derivative action time 1 (heating) [s], 2. parameter set

180

Td22 OFF/0,1...9999 Derivative action time 2 (cooling) [s], 2. parameter set

180
