Operation

9499-040-93811 / 59537-1

Page 13 of 88

Pro-16

circuit at controller off

- SSR defective

state relay

Loop Control loop alarm - Input signal defective

or not connected
correctly

- Output not connected
correctly

- Check heating or cooling circuit

- Check sensor and replace
it, if necessary

- Check controller and
switching device

AdA.H Self-tuning heating

alarm (

ADAH)

See Self-tuning heating
error status

see Self-tuning heating error
status

Ada.C Self-tuning cooling

alarm (

ADAC)

See Self-tuning cooling
error status

See Self-tuning cooling error
status

Lim.
1/2/3

stored limit alarm

adjusted limit value
1/2/3 exceeded

check process

Inf.1 time limit value

message

adjusted number of
operating hours reached

application-specific

Inf.2 duty cycle message

(digital ouputs)

adjusted number of duty
cycles reached

application-specific

3.5.2

Error-Status (Self-tuning)

(error status 3 - 9 only with error

AdA.H / AdA.C ):

Err-Status Description

Behaviour

1

Stored error

Delete the entry after acknowledgment

2

Existing error

Change to error status 1 after error removal

3

Faulty control action

Re-configure controller (inverse

i direct)

4

No response of
process variable

The control loop is perhaps not closed: check sensor,
connections and process

5

Low reversal point

Let process cool down and start new adaptation attempt

6

Danger of exceeded
set-point (parameter
determined)

If necessary, increase (inverse) or reduce (direct) set-
point

7

Output step change too
small

Let process cool down and start new adaptation attempt

8

Set-point reserve too
small

Increase set-point (invers), reduce (direkt)

9

Impulse tuning failed

The control loop is perhaps not closed: check sensor,
connections and process
