Configuration
level
9499-040-93811 / 59537-1
Page 38 of 88
Pro-16
6
è -Key function (see chapter 3.6 page 14)
7 Limit
1
8 Limit
2
9 Limit
3
P.oFF
Programmer Run/Stop (see page )
0
0
no function (switch-over via interface is possible)
2 DI1
3 Di
2
4
DI3 (only visible with OPTION)
5
DI4 (only visible with OPTION)
6
è -Key function (see chapter 3.6 page 14)
7 Limit
1
8 Limit
2
9 Limit
3
di.Fn
Function of digital inputs (valid for all inputs)
0
0 direct
1 inverse
2
toggle key function
fDI1
fDI2
fDI3
fDI4
Forcing di1/ di2 / di3 (only visible with BlueControl!)
0
0 No
forcing
1
Forcing via serial interface
othr
Name
Value range
Description
Default
bAud
Baudrate of the interface (only visible with OPTION)
2
0 2400
Baud
1 4800
Baud
2 9600
Baud
3 19200
Baud
Addr
1...247
Address on the interace (only visible with OPTION)
1
PrtY
Data parity on the interface (only visible with OPTION)
1
0
no parity (2 stop bits)
1 even
parity
2 odd
parity
dELY
0...200
Delay of response signal [ms] (only visible with OPTION)
0
Unit
Unit
1
0 without
unit
