Configuration
level
9499-040-93811 / 59537-1 Page 35 of 88 Pro-16
LOGI
Name Value range Description Default
L_r Local / Remote switching (Remote: adjusting of all values by
front keys is blocked) 0
0 no function (switch-over via interface is possible)
1 active
2 DI1
3 Di 2
4 DI3 (only visible with OPTION)
5 DI4 (only visible with OPTION)
6 è -Key function (see chapter 3.6 page 14)
7 Limit 1
8 Limit 2
9 Limit 3
SP.2 Switching to second setpoint SP.2 0
0 no function (switch-over via interface is possible)
2 DI1
3 Di 2
4 DI3 (only visible with OPTION)
5 DI4 (only visible with OPTION)
6 è -Key function (see chapter 3.6 page 14)
7 Limit 1
8 Limit 2
9 Limit 3
SP.E Switching to external setpoint SP.E 0
0 no function (switch-over via interface is possible)
1 active
2 DI1
3 Di 2
4 DI3 (only visible with OPTION)
5 DI4 (only visible with OPTION)
6 è -Key function (see chapter 3.6 page 14)
7 Limit 1
8 Limit 2
9 Limit 3
Y2 Y/Y2 switching 0
0 no function (switch-over via interface is possible)
2 DI1
