Programmer
9499-040-93811 / 59537-1 Page 66 of 88 Pro-16
8.3 Parameter
ProG
Name Value Range Description Default
b.Lo 0...9999 Bandwidth lower limit -32000
b.Hi 0...9999
Bandwidth upper limit
-32000
d.00
Resetvalue of control track 1 ... 4
0
0 track 1= 0; track 2= 0; track 3= 0; track 4= 0
1
track 1= 1; track 2= 0; track 3= 0; track 4= 0
2
track 1= 0; track 2= 1; track 3= 0; track 4= 0
3 track 1= 1; track 2=1; track 3= 0; track 4=0
4
track 1= 0; track 2= 0; track 3= 1; track 4= 0
5
track 1= 1; track 2= 0; track 3= 1; track 4= 0
6
track 1= 0; track 2= 1; track 3= 1; track 4= 0
7
track 1= 1; track 2= 1; track 3= 1; track 4= 0
8
track 1= 0; track 2= 0; track 3= 0; track 4= 1
9
track 1= 1; track 2= 0; track 3= 0; track 4=1
10
track 1= 0; track 2= 1; track 3= 0; track 4= 1
11 track 1= 1; track 2= 1; track 3= 0; track 4= 1
12
track 1= 0; track 2= 0; track 3= 1; track 4= 1
13
track 1= 1; track 2= 0; track 3= 1; track 4= 1
14 track 1= 0; track 2= 1; track 3= 1; track 4= 1
15
track 1= 1; track 2= 1; track 3= 1; track 4= 1
tYPE
segment type 1
0
0 time
1
gradient
2
hold
3 step
4
time and wait
5
gradient and wait
6 hold and wait
7
step and wait
8
end segment
SP -1999...9999 segment end set-point 1
Pt 0...9999
segment time/-gradient 1
d.Out
control track 1...4 - 1 (see parameter d. 00)
tYPE segment type 2 (see segment type 1) 0
