Configuration
level
9499-040-93811 / 59537-1
Page 30 of 88
Pro-16
23
special 0...4500 Ohm (pre-defined as KTY11-6)
30
0...20mA / 4...20mA Scaling is required (see chp. page 57)
40
0...10V / 2...10V Scaling is required (see chp. page 57)
S.Lin
Linearization (only at S.tYP = 23 (KTY 11-6), 30 (0..20mA)
and 40 (0..10V) adjustable) (see page 74)
0
0 Without
linearization
1
Linearization to specification. Creation of linearization table
with BlueControl (engineering tool) possible. The
characteristic for KTY 11-6 temperature sensors is preset.
Corr
Measured value correction / scaling
0
0 Without
scaling
1
Offset correction (at CAL level) (see page 58)
2
2-point correction (at CAL level 58)
3
Scaling (at PArA level) (see page 57)
fAI1
Forcing INP1 (only visible with BlueControl
®
!)
0
0 No
forcing
1
Forcing via serial interface
InP.2
Name
Value range
Description
Default
I.Fnc
Function selection of INP2
1
0
no function (subsequent input data are skipped)
1
heating current input
2 external
set-point
(
SP.E)
5
default correcting variable Y.E (switchover ->
LOGI/ Y.E)
S.tYP
Sensor type selection
31
30
0...20mA / 4...20mA Scaling is required (see chp. page 57)
31
0...50mA AC Scaling is required. (see chp. page 57)
fAI2
Forcing INP2 (only visible with BlueControl
®
!)
0
0 No
forcing
1
Forcing via serial interface
