West Control Solutions Pro-16 User Manual
Page 7

Mounting
9499-040-93811 / 59537-1
Page 7 of 88
Pro-16
Fig. 3: Mounting clip
Slip the mounting clip from
behind onto the housing until the
spring tab snaps in the latch.
After installing the instrument in the mounting plate, it may be removed from its housing, if
necessary (see the information on fitting and removing the optional modules).
g
NOTE!
The flanges of the mounting clip lock in position on both sides or on the top and
bottom side of the instrument housing. For optimum performance it is important
to use the latches on the sides of the instrument.
