KROHNE OPTISONIC 7300 EN - Manual (Page 86)

6
OPERATION
86
OPTISONIC 7300
www.krohne.com 09/2012 - 4001102303 - MA OPTISONIC 7300 R03 en
F application
error
Application-dependent error of the
complete device, device is however
ok.
F open circuit A
(or B, C)
Current on current output A (or B, C)
too low.
Check cable or reduce resistance
(< 1000 Ohm).
F over range A
(or B, C)
Current on current output A (or B, C)
is limited by parameter setting.
Extend upper or lower limit for
current output in menu C2. .8.
F over range A
(or B, D)
Pulse on frequency output A (or B, D)
is limited by parameter setting.
Extend upper or lower limit for
frequency output in menu C2. .7.
F active settings Error during CRC check (Cyclic
Redundancy Check) of the active
settings.
Load settings; factory setting, back
up 1 or back up 2.
F factory settings Error during CRC check of factory
settings.
F back up 1 (or 2)
settings
Error during CRC check of back up
1 (or 2) settings.
Save active settings in back up 1 or
back up 2.
F wiring A (or B) Current of current input is below 0.5
mA or above 23 mA.
Check connection of control input or
current input.
Open or short circuit of control input
A (or B).
F flow exceeding
limit
Over range, the meaured values are
limited by the filter setting.
Limitation fct. C1.3.1, increase
values.
F signal lost path
1 (or 2, 3)
Signal lost on path 1 (or 2,3). Check vacuum, composition of gas or
collection of liquid in transducer
tubes.
F transducer
delay
Invalid on-line measurement of the
transducer delay.
F temperature
input
No temperature data available.
F pressure input No pressure data available.
S out of
specification
Unreliable measurement. Maintenance required, check flow
profile.
S overflow
counter 1
(or 2, 3)
Counter is overflowing and will start
again at zero.
No action needed.
S backplane
invalid
Error during CRC check of
backplane.
Restore data records on backplane.
S error current A
(or B)
Error current at current input A
(or B).
S unreliable 1
(or 2 or 3)
Signal detection of path 1 (or 2 or 3)
is difficult due to excessive noise or
variations in the amplitude of the
received signal. The accuracy is not
guaranteed.
S frontend
calibration
Invalid calibration data of the
frontend.
S dsp timing
error
Ping time of the frontend is too short.
C checks in
progress
Test run of the device, measured
value can be set to simulated
measured values or to a fixed value.
C simulation flow Sensor electronics simulates
measurement of volume flow.
Error Error Error Error
code
code code code
Error Error Error Error
message
message message message
Description Description Description Description Error handling Error handling Error handling Error handling
