C2. .11 phase shift w.r.t. B Only available when configuring the A or D terminal and only if output
B is a pulse or frequency output. If setting in Fct. C2.5.6 is "both
polarities", the phase shift is prefixed by a symbol, e.g. -90° and +90°.
Select: off (no phase shift) /
0° phase shift (between outputs A or D and B, inversion possible) /
90° phase shift (between outputs A or D and B, inversion possible) /
180° phase shift (between outputs A or D and B, inversion possible)
C2. .12 information
1
st
line: serial number of the I/O circuit board
2
nd
line: software version number
3 rd line: production date of the circuit board
C2. .13 simulation Sequence see B1. frequency output X
pulse output X
C2. pulse output X X stands for one of the connection terminals A, B or D.
stands for A, B or D.
C2. .1 pulse shape Specify the pulse shape.
Select: symmetric (about 50% on and 50% off) / automatic (constant
pulse with about 50% on and 50% off at 100% pulse rate) / fixed (fixed
pulse rate, setting see below Fct. C2. .3 100% pulse rate)
C2. .2 pulse width Set time for pulse activation.
Only available if Fct. C2. .1 is set to "Fixed".
Range: 0.05…2000 ms
Note: max. setting value T
p
[ms] ≤ 500 / max. pulse rate [1/s], gives the
pulse width = time where the output is activated.
C2. .3 max. pulse rate Pulse rate for 100% of the measuring range.
Range: 0.0…10000 Hz
Limitation 100% pulse rate ≤ 100/s: I
max
≤ 100 mA
Limitation 100% pulse rate > 100/s: I
max
≤ 20 mA
C2. .4 measurement Measurements for activating the output.
Select: volume flow / mass flow / corr. volume flow
C2. .5 value p. pulse Set value for volume or mass per pulse.
xxx.xxx (format and unit depend on the measured variable)
At max. pulse rate see above C2. .3 pulse output.
C2. .6 polarity Set polarity, please note flow direction in C1.3.2!
Select: both polarities (plus and minus values are displayed) / positive
polarity (display for negative values = 0) / negative polarity (display for
positive values = 0) / absolute value (use for the output)
C2. .7 low flow cutoff Below set value, pulse output is set to zero.
x.xxx ± x.xxx%
Range: 0.0…20%
1 st value = switching point / 2 nd value = hysteresis
Condition: 2 nd value ≤ 1 st value
C2. .8 time constant Averages measurement
Increasing value improves stability but delays the reaction.
Range: 000.1…100 s
