6
OPERATION
80
OPTISONIC 7300
www.krohne.com 09/2012 - 4001102303 - MA OPTISONIC 7300 R03 en
C5. .7 format 1.line Specify decimal places.
Select: automatic (adaptation carried out automatically) /
X (= none) …X.XXXXXXXX (max. 8 digits)
C5. .8 measurement 2.line
Specify measurement 2 nd line
(only available if this 2 nd line is activated)
Select: bar graph (for the measurement selected in 1 st line) / volume
flow / corr. volume flow / mass flow / molar mass / flow speed /
velocity of sound / gain / diagnostics 1, 2, 3 / counter 1, 2, 3 / bargraph /
operating hours
C5. .9 format 2.line Specify decimal places.
Select: automatic (adaptation carried out automatically) /
X (= none) …X.XXXXXXXX (max. 8 digits)
C5. .10 measurement 3.line
Specify measurement 3 rd line
(only available if this 3 rd line is activated)
Select: volume flow / corr. volume flow / mass flow / molar mass / flow
speed / velocity of sound / gain / diagnostics 1, 2, 3 / counter 1, 2 /
operating hours
C5. .11 format 3.line Specify decimal places.
Select: automatic (adaptation carried out automatically) /
X (= none) …X.XXXXXXXX (max. 8 digits)
C5.5 graphic page
C5.5.1 select range
Graphic page always shows trend curve of the measurement of the 1 st
page / 1 st line, see Fct. C5.3.2.
Select: manual (set range in Fct. C5.5.2)
Automatic (automatic depiction based on the measured values)
Reset only after parameter change or after switching off and on.
C5.5.2 range Set the scaling for the Y axis.
Only available if "manual" is set in C5.5.1.
+xxx ±xxx%
Range: -100…+100%
1
st
value = lower limit / 2
nd
value = upper limit
Condition: 1
st
value ≤ 2
nd
value
C5.5.3 time scale Set the time scaling for the X axis, trend curve.
xxx min
Range: 0…100 min
C5.6 special functions
C5.6.1 reset errors Reset?
Select: no/yes
C5.6.2 save settings Save current settings.
Select: cancel (exit function without saving) / backup 1 (save in storage
location 1) / backup 2 (save in storage location 2)
Query: go on with copy? (can not be undone).
Select: no (exit function without saving) / yes (copy current settings to
storage backup 1 or backup 2)
