9
DESCRIPTION OF HART INTERFACE
130
OPTISONIC 7300
www.krohne.com 09/2012 - 4001102303 - MA OPTISONIC 7300 R03 en
9.11.9 Offline Root Menu
Identification Identification Identification Identification
Identification Tag / Descriptor / Message / Date
Device
Manufacturer
Rd
/ Device Type
Rd
/ Device ID
Rd
/ Final Assembly Number / C number
Rd
/
Device Serial No. Rd / Electronic Serial No. Rd
Detailed Setup Detailed Setup Detailed Setup Detailed Setup
Mapping of Variables
Mapping of Variables
PV is Rd / SV is / TV is / QV is
Process Input
Calibration Meter Size / GK
Filter Minimum Limit / Maximum Limit / Flow Direction / Time Constant /
Threshold Low Flow Cutoff / Hysteresis Low Flow Cutoff
Plausibility Error Limit / Counter Decrease / Counter Limit
Information Serial Number Sensor / V Number Sensor
VoS monitor Opt Monitor Velocity of Sound
Monitor Settings Opt Monitor Settings Opt Monitor Settings Opt Monitor Settings Opt
Matching Factor / Actual Ratio Measurement/Calibration / VoS Tolerance / Time Constant
Linearization
Linearization / Dynamic Viscosity Opt
General Opt Adiabatic Index
P&T Correction Opt P&T Correction / P&T Inputs Opt / Pipe Temperature Opt /
Pipe Pressure Opt / Density Opt
Diagnosis Value Diagnosis 1 / Diagnosis 2 / Diagnosis 3
HART Sensor s/n /
Actual Flow, Corrected Flow Actual Flow, Corrected Flow Actual Flow, Corrected Flow Actual Flow, Corrected Flow Opt Opt Opt Opt , Enthalpy Flow Enthalpy Flow Enthalpy Flow Enthalpy Flow Opt Opt Opt Opt , Mass Flow , , Mass Flow , , Mass Flow , , Mass Flow , …
Unit / Format / Upper Sensor Limit / Lower Sensor Limit / Minimum Span
I/O
Hardware Terminals A / Terminals B / Terminals C / Terminals D
Current Output A/B/C Opt Range 0% Cust / Range 100% Cust / Extended Range Min Cust / Extended Range Max Cust /
Error Current
Cust
/ Error Condition
Cust
/ Measurement
Cust
/ Range Min
Cust
/
Range Max Cust / Polarity Cust / Limitation Min Cust / Limitation Max Cust /
LFC Threshold Cust / LFC Hysteresis Cust / Time Constant Cust / Special Function Cust /
Threshold Range Change Opt, Cust / Hysteresis Range Change Opt, Cust
Frequency Output
A/B/D
Opt
Pulse Shape Opt, Cust / Pulse Width Opt, Cust / 100% Pulse Rate Opt, Cust / Measurement Cust /
Range Min Cust / Range Max Cust / Polarity Cust / Limitation Min Cust /
Limitation Max Cust / LFC Threshold Cust / LFC Hysteresis Cust / Time Constant /
Invert Signal Cust / Special Function Opt, Cust / Phase Shift Opt, Cust
Pulse Output A/B/D Opt Pulse Shape Opt, Cust / Pulse Width Opt, Cust / Max. Pulse Rate Opt, Cust / Measurement Cust /
Pulse Value Unit Rd, Cust / Value Per Pulse Cust / Polarity Cust / LFC Threshold Cust /
LFC Hysteresis Cust / Time Constant / Invert Signal Cust / Special Function Opt, Cust /
Phase Shift Opt, Cust
Status Output A/B/C/D Opt Mode / Output A Opt / Output B Opt / Output C Opt / Output D Opt / Invert Signal
