9
DESCRIPTION OF HART INTERFACE
120
OPTISONIC 7300
www.krohne.com 09/2012 - 4001102303 - MA OPTISONIC 7300 R03 en
9.11 HART Menu Tree
9.11.1 HART Menu Tree - Field Communicator HART Application
The Field Communicator supports the standard EDDL Root Menu.
In the signal converter HART DD it is implemented as a combination of other standard EDDL
menus:
• Process Variables Root Menu (details on page 124)
• Diagnostic Root Menu (details on page 125)
• Device Root Menu (details on page 127)
The menus are located in the Field Communicator user interface as follows:
Field Communicator HART Application
1 Offline
2 Online 1 Process Variables (Process Variables Root Menu)
2 Diag/Service (Diagnostic Root Menu)
3 Quick Setup (Device Root Menu)
4 Detailed Setup (Device Root Menu)
5 Service (Device Root Menu)
3 Utility
4 HART Diagnostics
