Maximum number of PoE class 3 (15.4W) ports per power supply TABLE 1
Power Supply Number of Power Supplies FSX 800 FSX 1600
SX-ACPWR-PoE and SX-DCPWR-PoE 1 70 70
SX-ACPWR-PoE and SX-DCPWR-PoE 2 140 140
SX-ACPWR-PoE and SX-DCPWR-PoE 3 N/A 210
SX-ACPWR-PoE and SX-DCPWR-PoE 4 N/A 280
SX-ACPWR2500-PoE 1 146 140
SX-ACPWR2500-PoE 2 292 280
SX-ACPWR2500-PoE 3 N/A 4381
SX-ACPWR2500-PoE 4 N/A 5841
PoE+ port density
NOTE
PoE+ is supported on the FI-SX-24-GPP and FI-SX48GPP interface modules for FSX 800 and FSX
1600 devices only.
To determine the maximum number of PoE+ Class (30W) ports available per power supply, use the
calculation: One power supply (1080W) over power consumed by PoE+ port (30W)= 1080W/30W = 36
ports.
The table below shows the maximum PoE+ port density for the FI-SX-24-GPP and FI-SX48GPP
interface modules.
Maximum number of PoE+ class (30W) ports per power supply TABLE 2
Power Supply Number of Power Supplies FSX 800 FSX 1600
SX-ACPWR-PoE and SX-DCPWR-PoE 1 36 36
SX-ACPWR-PoE and SX-DCPWR-PoE 2 72 72
SX-ACPWR-PoE and SX-DCPWR-PoE 3 N/A 108
SX-ACPWR-PoE and SX-DCPWR-PoE 4 N/A 144
SX-ACPWR2500-PoE 1 75 75
SX-ACPWR2500-PoE 2 150 150
SX-ACPWR2500-PoE 3 N/A 225
1 The FSX 800 supports a maximum of 192 PoE ports. The FSX 1600 supports a maximum of 384 PoE ports.
PoE+ port density
