Brocade Multi-Service IronWare Security Configuration Guide (Supporting R05.6.00) - Manual (Page 360)

342 Multi-Service IronWare Security Configuration Guide
53-1003035-02
Using the User-Based Security model
10
The engine ID identifies the source or destination of the packet.
The engine boots represents the number of times that the SNMP engine reinitialized itself with the
same engine ID. If the engineID is modified, the boot count is reset to 0.
The engine time represents the current time with the SNMP agent.
Displaying SNMP groups
To display the definition of an SNMP group, enter a command such as the following.
Brocade(config)# show snmp group
groupname = exceptifgrp
security model = v3
security level = authNoPriv
ACL id = 2
readview = exceptif
writeview =
Syntax: show snmp group
The value for security level can be one of the following.
Displaying user information
To display the definition of an SNMP user account, enter a command such as the following.
Syntax: show snmp user
Security level Authentication
none If the security model shows v1 or v2, then security level is
blank. User names are not used to authenticate users;
community strings are used instead.
noauthNoPriv Displays if the security model shows v3 and user
authentication is by user name only.
authNoPriv Displays if the security model shows v3 and user
authentication is by user name and the MD5 or SHA
algorithm.
authPriv Authentication uses MD5 or SHA. Encryption uses DES and
AES protocol.
Brocade(config)# show snmp user
username = bob
acl id = 0
group = bobgroup
security model = v3
group acl id = 0
authtype = md5
authkey = ad172674ebc09cd9448c8276db0d12f8
privtype = aes
privkey = 3c154b47996534b22b22758e23f9a71a
engine ID= 800007c703000cdbf48a00
