Sample 802.1x configurations
8
The following commands configure the device in Figure 7 .
Brocade(config)# aaa authentication dot1x default radius
Brocade(config)# radius-server host 192.168.9.22 auth-port 1812 acct-port 1813
default key mirabeau dot1x
Brocade(config)# dot1x-enable
Brocade(config-dot1x)# enable e 2/1 to 2/3
Brocade(config-dot1x)# re-authentication
Brocade(config-dot1x)# timeout re-authperiod 2000
Brocade(config-dot1x)# timeout quiet-period 30
Brocade(config-dot1x)# timeout tx-period 60
Brocade(config-dot1x)# max-req 6
Brocade(config-dot1x)# exit
Brocade(config)# interface e 2/1
Brocade(config-if-e100-1)# dot1x port-control auto
Brocade(config-if-e100-1)# exit
Brocade(config)# interface e 2/2
Brocade(config-if-e100-2)# dot1x port-control auto
Brocade(config-if-e100-2)# exit
Brocade(config)# interface e 2/3
Brocade(config-if-e100-3)# dot1x port-control auto
Brocade(config-if-e100-3)# exit
RADIUS Server
(Authentication Server)
NetIron Device
(Authenticator)
Clients/Supplicants running 802.1X-compliant client software
192.168.9.22
e2/1 e2/2 e2/3
