Configuring numbered and named ACLs
3
3. Enter the show access-list command to display the updated list.
Brocade(config)# ip show access-list name entry
Standard IP access list entry
10: deny host 10.2.4.5
30: deny host 10.6.7.8
40: permit any
NOTE
If you try to delete an ACL filter rule using the sequence number, but the sequence number that you
specify does not exist, the following error message will be displayed.
"Error: Entry with sequence 20 does not exist!"
Syntax: [no] ip access-list standard string | num
Syntax: [no] [sequence num] deny | permit [vlan vlan-id] host {source-ip | hostname} |
{hostname wildcard | source-ip/mask-bits} | any
Syntax: regenerate-seq-num [num]
Syntax: [no] ip access-group num in
The standard parameter indicates the ACL type.
The string parameter is the ACL name. You can specify a string of up to 256 alphanumeric
characters. You can use blanks in the ACL name if you enclose the name in quotation marks (for
example, “ACL for Net1”). The num parameter allows you to specify an ACL number if you prefer. If
you specify a number, you can specify from 1 – 99 for standard ACLs or 100 – 199 for extended
ACLs.
NOTE
For convenience, the software allows you to configure numbered ACLs using the syntax for named
ACLs. The software also still supports the older syntax for numbered ACLs. Although the software
allows both methods for configuring numbered ACLs, numbered ACLs are always formatted in the
startup-config and running-config files in using the older syntax, as follows.
access-list 1 deny host 10.157.22.26
access-list 1 deny 10.157.22.0 0.0.0.255
access-list 1 permit any
access-list 101 deny tcp any any eq http
The options at the ACL configuration level and the syntax for the ip access-group command are the
same for numbered and named ACLs and are described in
“Configuring standard numbered ACLs” .
Configuration example for extended ACL
To configure a named extended ACL entry, enter commands such as the following.
Brocade(config)# ip access-list extended “block Telnet”
Brocade(config-ext-nacl-block telnet)# deny tcp host 10.157.22.26 any eq
Brocade(config-ext-nacl-block telnet)# permit ip any any
Brocade(config-ext-nacl-block telnet)# exit
Brocade(config)# int eth 1/1
Brocade(config-if-e10000-1/1)# ip access-group “block Telnet” in
