• Enabling dynamic VLAN support for tagged packets on non-member VLAN ports is not supported
on FWS and FCX devices.
• The mac-authentication disable-ingress-filtering command is not available on the ICX 6610 and
ICX 6450 platforms.
Specifying to which VLAN a port is moved after its RADIUS-specified VLAN assignment expires
When a port is dynamically assigned to a VLAN through the authentication of a MAC address, and the
MAC session for that address is deleted on the Brocade device, then by default the port is removed
from its RADIUS-assigned VLAN and placed back in the VLAN where it was originally assigned.
A port can be removed from its RADIUS-assigned VLAN when any of the following occur:
• The link goes down for the port
• The MAC session is manually deleted with the mac-authentication clear-mac-session command
• The MAC address that caused the port to be dynamically assigned to a VLAN ages out
For example, say port 1/1 is currently in VLAN 100, to which it was assigned when MAC address
0000.00a1.e90f was authenticated by a RADIUS server. The port was originally configured to be in
VLAN 111. If the MAC session for address 0000.00a1.e90f is deleted, then port 1/1 is moved from
VLAN 100 back into VLAN 111.
You can optionally specify an alternate VLAN to which to move the port when the MAC session for the
address is deleted. For example, to place the port in the restricted VLAN, enter commands such as the
following.
device(config)#interface e 3/1
device(config-if-e1000-3/1)#mac-auth move-back-to-old-vlan port-restrict-vlan
Syntax: [no] mac-authentication move-back-to-old-vlan [ port-restrict-vlan | port-configured-
vlan | system-default-vlan ]
The port-configured-vlan keyword removes the port from its RADIUS-assigned VLAN and places it
back in the VLAN where it was originally assigned. This is the default.
The port-restrict-vlan keyword removes the port from its RADIUS-assigned VLAN and places it in the
restricted VLAN.
The system-default-vlan keyword removes the port from its RADIUS-assigned VLAN and places it in
the DEFAULT-VLAN.
NOTE
When a MAC session is deleted, if the port is moved back to a VLAN that is different than the running-
config file, the system will update the running-config file to reflect the changes. This will occur even if
mac-authentication save-dynamicvlan-to-config" is not configured.
Automatic removal of dynamic VLAN assignments for MAC authenticated ports
NOTE
This feature is not supported on ICX 6610 and FCX devices.
By default, the Brocade device removes any association between a port and a dynamically-assigned
VLAN when all authenticated MAC sessions for that tagged or untagged VLAN have expired on the
port. Thus, RADIUS-specified VLAN assignments are not saved to the device running-config file.
When the show run command is issued during a session, dynamically-assigned VLANs are not
